The relay can have a mechanical problem, like the spring wears out. That has a 10^7 switches min. lifetime on this datasheet. Or the relay contacts can wear out, typically due the the small arcing that happens when you switch higher currents, so that depends on the current and voltage switched.

18/08/2005 · Silver contacts lifetime - relay switch kr7 (Electrical) (OP) 16 Aug 05 16:40. Hi, I am trying to figure out the reliable lifetime of the silver contacts in a pressure switch. I am trying to use this switch in a logic circuit as relay control. Since the switch serves a failsafe function in the device (it senses over pressure in the system), it ...

Modern semiconductor technology enables fast, quiet, bounce-free switching, even in miniature sizes. PhotoMOS relays nevertheless enjoy an almost unlimited lifetime if used according to the specifications. Moreover, they are extremely reliable, unaffected by vibrations, and their ON-resistance remains stable throughout their entire lifetime.

Relay contacts, being basically large pieces of metal, have much greater tolerance to this application, but even so, breaking large load currents will eventually burn out relay contacts. If you need to switch something faster than once every second, a relay would probably have a relatively short life, and it would be worthwhile to go with the ...

28/01/2015 · Looking up the topic, I found an NI page pegging a relay lifetime to about 10^5 cycles and showing how their switching products tracked relay actuations (and the counters are software accessible). Looking at my little experiment, I was drawing about 1000 points, so that's a few 1000s relay actuations, a non-negligible fraction of 10^5.

A solid-state relay (SSR) is an electronic switching device that switches on or off when a small external voltage is applied across its control terminals. SSRs consist of a sensor which responds to an appropriate input (control signal), a solid-state electronic switching device which switches power to the load circuitry, and a coupling mechanism to enable the control signal to activate this ...

The relay is a double pole double throw switch. Its typical lifetime is 100,000 switching cycles, depending on how heavy a load you are using. DoubleSwitch does not supply power at the screw terminals. Activation of this switch will power up both outputs at the same time. INDIVIDUAL CONTROL OF THE TWO POWER OUTPUTS IS NOT POSSIBLE. SPECIFICATIONS:

Relay Basics: A relay is an electrical switch that uses an electromagnet to move the switch from the off to on position instead of a person moving the switch. It takes a relatively small amount of power to turn on a relay but the relay can control something that draws much more power. Ex: A relay is used to control the air conditioner in your home.

When asked to hot switch a load, a relay may only be good for 100,000 operations. On the other hand, if a signal is cold-switched, i.e. is applied only after the relay contacts have been operated, the relay's lifetime will be much longer and approach the relay's mechanical life.

05/03/2019 · Because of the smaller, less massive contacts and the different actuating mechanism, a reed relay can switch about 10 times faster than an electromechanical relay with equivalent ratings. The reed relays’s mechanical lifetime is also much higher than an electromechanical relay.
